1.Product Introduction
The customized intelligent computer room host ROC-D has power supply and distribution, UPS, air conditioning, water leakage, temperature and humidity, infrared, access control, etc. for centralized monitoring and management alarm functions, the host provides working power for various sensors, and can use the built-in backup power supply to independently provide power to the host and sensors in the state of power failure, and supports open interface protocols such as JSON and ModbusTCP to achieve remote centralized monitoring and management.
2.Product Parameter (Specification)
| Parameter Category | Parameter Details |
| Core Hardware |
Processor: Industrial-grade ARM Cortex-A9/A53 quad-core (customizable for high-performance models) Storage: Built-in 64G eMMC (expandable to 256G); supports 2.5-inch SATA HDD/SSD (max 4TB); 1x TF card slot (max 128G) |
| Operating System | Linux (customizable with Debian/Ubuntu-based embedded systems); supports secondary development of system kernels |
| Network Interface |
2x 10/100/1000M adaptive RJ45 Ethernet ports (support POE+ optional, IEEE 802.3at standard, single-port max 30W) Optional 4G/5G wireless module (Supporting All-network bands) or Wi-Fi 6 module |
| Serial Interfaces |
8-16x RS485/RS232 configurable ports (RJ45 interface, 12VDC/24VDC optional power supply for sensors; 2500Vrms electrical isolation) 2x RS232 debug ports (DB9 interface) |
| USB Interface | 2x USB 3.0 ports (for external storage/Peripherals); 1x USB 2.0 port (for maintenance) |
| Digital I/O |
Digital Input: 16-32x optocoupler-isolated DI ports (RJ45, support dry contact/wet contact) Digital Output: 8-16x relay DO ports (max 5A/250VAC, normally open/normally closed configurable) |
| Supported Protocols |
Standard: ModBus-RTU/TCP, IEC 61850, IEC 104, BACnet MS/TP Customizable: Private protocols for third-party devices (e.g., UPS, precision air conditioner, access control systems) |
| Alarm & Notification |
Local: Buzzer + 4-color status LED (power/run/alarm/network) Remote: SMS, email, WeChat, SNMP Trap (customizable for platform-specific protocols like MQTT) |
3.Product Feature And Application
The monitoring host adopts low-power ARM chip and embedded operating system, built-in hardware watchdog, with fault automatic recovery function, when the host is restarted, the entire monitoring system is also running, built-in WEB server, support B/S architecture, managers can directly view the operating status of all power environment monitoring equipment in the computer room in real time through the browser and corresponding permissions, can remotely manage and adjust the working parameters of related equipment.
4.Product Details
The customized intelligent computer room host ROC-D is suitable for government, electric power, military, banking, telecommunications, education, hospitals, airports, railways, factories, hotels, warehouses, transportation and other industries, and is designed for the integrated monitoring of power, environment, security and network in computer network rooms, communication rooms, communication base stations, power base stations, substations, residential distribution stations, UPS computer rooms, battery pack rooms, outdoor cabinets, unattended sites, warehouses and other scenarios.
5.Deliver,Shipping And Serving
If the regular model is in stock, it can be shipped within 3-5 working days after the order is confirmed and payment is completed, with a free warranty of 2 years from the date of delivery of the device, of which the backup lithium battery warranty period is 1 year.
6. How to install?
For the installation of ROC-D of the customized smart computer room host, you need to first prepare the equipment, accessories and tools and select the installation position, then fix the bracket and host, then connect the power supply, network and peripherals, check the indicator light after powering on and configure the networking through the WEB / mini program / platform, and finally simulate the collection of data to verify the upload and alarm functions.
