1.Product Introduction
1.The explosion-proof temperature and humidity transmitter RS-FPC-WS-N01 features a high-end European imported temperature measurement unit that delivers precise readings even in harsh environments.
2.It supports remote infrared control for parameter adjustment without disassembly, ensuring convenient and efficient operation.
3.With a communication range up to 2km, it adopts the standard RS485 interface and ModBus-RTU protocol, allowing customizable address and baud rate settings.
4.The device incorporates an advanced wall-mounted explosion-proof housing that's easy to install, boasts IP65 protection rating, and demonstrates strong durability suitable for operation in various harsh environments.
5.Supporting 10-30V wide-range DC power input, it's compatible with diverse industrial DC power supply systems.
6.An optional high-definition LED display ensures clear visibility of all readings even in complete darkness.
2.Product Parameter
| Product Model | RS-FPC-WS-N01 | Work Environment | -20℃~+60℃，0%RH~100%RH |
| Communication Interface | RS-485 | Measurement Range | -20℃~+60℃，0%RH~100%RH |
| Communication Protocol | MODBUS | Power Consumption | 0.35W |
| Relay Load Capacity | 250VAC 1A/30VDC 1A | Work Power Supply | DC10-30V |
| Display Accuracy | 0.1 | Main Body Dimensions | 80*80*30mm |
| Accuracy |
Hum: ±3%RH Tem: ±0.5℃ |
Installation Method | Wall Mounted |
| Explosion-proof marking | Ex d IIC T6 Gb |
3.Product Feature And Application
The RS-FPC-WS-N01 explosion-proof temperature and humidity monitoring device is designed to meet demanding outdoor environmental detection requirements. It delivers precise monitoring and timely alarms in various critical locations including chemical warehouses, power distribution rooms, military storage facilities, and laboratories. In high-temperature and explosive environments, this equipment plays a vital role in ensuring personnel safety and minimizing potential losses.
4.Product Details
The RS-FPC-WS-N01 features wall-mounted installation suitable for multiple application scenarios. Operating on 10-30V DC power supply, it incorporates LED display that intuitively presents temperature and humidity readings directly on the sensor for straightforward operation.
5.Deliver,Shipping And Serving
We consistently utilize internationally certified eco-friendly cushioning packaging to ensure zero damage during product transportation. Our pre-sales service features a dedicated consultant team providing personalized customization solutions, while post-sales support encompasses warranty coverage, rapid response, and comprehensive technical assistance.
6.FAQ
Q: What is the explosion-proof rating of the product? Does it comply with international standards?
A:The product’s explosion-proof certification meets the latest international standards (including ATEX and IECEx) with an Ex d IIC T6 Gb rating. Specifically engineered for harsh environment monitoring, it provides reliable protection for both production operations and property safety.
7.Company Introduction
Maishi Information Technology Co., Ltd. has been focused on the research and development of smart data center systems for over 10 years. It is a manufacturer of power and environment products, as well as a provider of data center monitoring system solutions, integrating research and development, production, sales, and service. The company is located in the ASEAN Enterprise Headquarters Base in the High-tech Development Zone.
Maishi core competitiveness lies in its online marketing capabilities, personalized customization capabilities, and small-batch production capabilities. We empower our partners to have their own brand models, parameter specifications, price costs, and innovative highlights.
